Line-spray pulse bag dust collector is used to remove and collect solid particles in gas. It is suitable for dust collection of large-volume high-temperature gas in cement clinker coolers, kiln tails, raw material mills, dryers, etc.; it can be used for finished material powder collection and dust removal processes in various cement, slag, and coal powder grinding systems; it is also suitable for waste gas dust removal in metallurgy, power, chemical industry, machinery, and civil boilers. The minimum emission concentration can reach 2mg/Nm3.

●The specially-designed walk-in plenum structure facilitates the replacement of filter bags from inside the filter housing, thus ensuring air leakage to be under 2.5%, to prevent corrosion by rust and to lower energy consumption of the fans due to minimum of false air;

●Optimum structure ensured by CFD-based gas distribution, de-dusting simulation and the overall optimization of the equipment;

●Key devices, the purge tube and the purge unit, are patented with several national invention and utility model patents. De-dusting efficiency and extended service life of the pulse valve and the filter bag can thus

be guaranteed;

●Modular design, easy for erection at site and for applying sealing welds;

●The well-designed de-dusting control system is PLC-based, which allows to conveniently adjust the mode,

interval and intensity of the de-dusting program and to display all relevant operational parameters;

●A smart monitoring system is used, which ensures reliable operation of this important process equipment.
